Prefab Houses Low Cost Cheap Steel Living 20Ft Container House

  • 5 - 9 Units
    US $1900.00
  • >=10 Units
    US $1890.00
Material:
Container Sandwich Panel Steel
Customization:
Customized logo (Min. Order: 10 Units)
Customized packaging (Min. Order: 10 Units)

More

Graphic customization (Min. Order: 10 Units) Less
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
Shandong, China (Mainland)
Brand Name:
DFX
Model Number:
Steel 20Ft Container House
Use:
House, Office, Shop, Workshop
Item:
Prefab Houses Low Cost Cheap Steel Living 20Ft Container House
Surface:
Galvanized or Painted
Grade:
Q345 & Q235 steel
Type:
Light Steel Struture
Application:
Carport, Hotel, House, Kiosk, Booth
Keyword:
Container House
Door:
As your required
Delivery:
25 Days
Payment:
T/T L/C or as your required
Inner decoration design:
customer's requirement
Supply Ability
Supply Ability:
5000 Set/Sets per Month container house
Packaging & Delivery
Packaging Details
container house:
1,All the steel columns and beams ends and plates will be packed by the blanket.
2,All the wall and roof panels will be filmed by two sides and fixed stably in the 40'HQ container.
3,To make the loading and unloading more efficiently and saving the delivery cost,40'OT is preferred to loading the steel frames.
4,We also can pack according to your required.
Port
Qingdao
Lead Time :
Quantity(Units) 1 - 100 101 - 500 >500
Est. Time(day) 15 30 To be negotiated

Prefab Houses Low Cost Cheap Steel Living 20Ft Container House

Director Group steel structure container house has features of high fire resistance, strong corrosion resistance. Steel structure warehouse is mainly refers to the main bearing component is composed of steel. Including the steel columns, steel beam, steel structure, steel roof truss.Each component using welds, bolts or rivets to connect.



The roof and wall can be made of composite panel or veneer. Galvanized sheet metal can prevent rust and corrosion. The use of self-tapping screw can make the connection between the plates more closely, to prevent leakage. You can also use composite panel for roof and wall. The sandwich is polystyrene, glass fiber, rock wool, polyurethane. They have good thermal insulation, heat insulation, fire-retardant. The wall of the steel structure maintenance also can use brick wall. The cost of a brick wall is higher than galvanized steel roof and wall.



The usage scale includes large-scale workshop, or warehouse, supermarkets, entertainment centers and modular steel structure garage.

Product Description

1_container_house.jpg2_container_house.jpg 2.  Specification



 Specification for

 export box:

3  m x 6 meter

standard box

 Long (mm) 5800
 Width (mm) 2440
 High (mm) 2620
 Roof form Flat roof, free fall
 The layer number Three layers or less
 Design Parameters

 Years of use of structural

 design

 20 years
 Floor live load 2.0KN/sqm, or: 200kg/sqm
 Roof live load 0.5KN/sqm, or: 50kg/sqm
 Wind load 0.6KN/sqm, or: 112km/h
 Seismic fortification intensity 8 degrees
 Structure Angle

 Galvanized square pipe, thickness of 2.5mm,

 material Q235B

 Roof girder

 Galvanized square pipe, thickness of 2.5mm,

 material Q235B

 Roof second beam

 Galvanized square pipe, thickness of 2.5mm,

 material Q235B

 The main girder

 Galvanized square pipe, thickness of 2.5mm,

 material Q235B

 The ground secondary beam

 Galvanized square pipe, thickness of 2.5mm,

 material Q235B

 The paint

 Non-toxic and odorless environmental water-based

 paint, waterproof, wear-resistant, aging resistant,

 yellow - resistant and fast drying

 Roof Roof panel Roof thickness: 0.8mm
 Heat preservation cotton

 Double layer 100mm thick glass fiber felt, the bulk

 density is greater than 14kg/m cubed, and the

 combustion performance is not flammable at class A

 Ceiling board 0.5mm thick aluminum zinc plate, color white grey
 The ground Glass magnesium board

 15mm thick glass magnesium plate, the density is

 greater than 1.3 g/cm3, the combustion performance

 is not combustible at grade A, and the surface is

 added to the surface

 Wall Rock wool board

 50mm thickness of colored steel glass silk sandwich

 plate, inside and outside the thickness of 0.4mm

 aluminum zinc coated steel plate, 50mm thick colored

 steel glass silk sandwich board; The color is white

 Heat preservation

 50mm thick glass silk, the bulk density is greater

 than kg/cm3, the combustion performance is not A grade

 The door Specification (mm) Wide high X =950*2050
 The material

 Steel door, matching advanced door and door lock

 hardware fitting for housing service life requirement

 Window Specification (mm) 950*1200, 2 sets
 The framework material Model steel hollow
 Glass Layer 2
 Electricity Voltage 220V~250V
 The wire

 The total power cord of the household is 6 square,

 the air-conditioner line is 4 square, the socket line is

 4 square, and the lighting switch line is 1.5 square

 The circuit breaker

 Independent high scoring break small circuit breaker

 leakage protection switch

 Tube The LED fluorescent lamp
 The socket Two five-hole sockets 10A, national standard
Product Show

 Container house_jpg032Container house_jpg026Container house_jpg028Container house_jpg025

Main Material

steel structure



      H-Shaped Steel

The advantages of our products:

high-performance thermal

insulation, ventilation,

moisture-proof materials

provide extremely high

living comforts.



      C-Shaped Steel

The advantages of this approach is

durable life long, the production of

high degree of industrialization,

quality and stability. So heavily

used by atmospheric corrosion

is serious and difficult

maintenance of outdoor steel

structure.



     Sandwich Panel

Sandwich panel is suitable for prejects with high fireproof requirement. With good sound-proof effect.In addition, noise indoor caused by rain and hail are weakened obviously after sandwich used.

steel structure

Steel frame structure consists of beams and columns from welded H-shapede steel, hot rolled H-shaped steel. In this frames, the beam and column system takes the gravity load such as dead and live loads..


Company Information
steel structure

ABOUT US

Qingdao Director Steel Structure Co., Ltd. is a China based manufacturer of steel structure building, prefabricated house and related steel products.

Factory established in 1997

Area of the factory: 40000 square meter

Workshop area: 20000 square meter

Production lines:

5 lines for H section steel

3 lines for steel purlin

3 lines for corrugated color steel

3 lines for sandwich panel

Certificate -Quality Control.jpg

8 Certification-package.jpg

Prefab Houses Low Cost Cheap Steel Living 20Ft Container House

FAQ
Q

You are manufacture factory or trading company?

A

We are manufacture factory. And you are welcomed to visit us for inspection. The quality control flow will show you ourprofessional. Also you will enjoy the best quality and competitive price.

Q

You are manufacture factory or trading company?

A

We are manufacture factory. And you are welcomed to visit us for inspection. The quality control flow will show you ourprofessional. Also you will enjoy the best quality and competitive price.

Q

Whats the quality assurance you provided and how do you control quality ?

A

Established a procedure to check products at all stages of the manufacturing process - raw materials, in process materials, validated or tested materials, finished goods, etc. SGS, BV and other testing are available for us. We could deal with you by Trade Assurance via Alibaba.

Q

Can you offer designing service?

A

Yes, we have more than 10 design engineers. We could design full solution drawings as per your requirments. They use software: Auto CAD,PKPM, MTS, 3D3S, Tarch, Tekla Structures(Xsteel)V12.0.etc.



Q

Do you offer guiding installation on site overseas?

A

Yes, usually we will send you the detailed installation drawing, if you need, we can provide the service of installation, supervision and training by extra. We can send our professional technical engineer to supervise installation on site overseas.
